MMD36E, 8.3kW
The Liebert Mini-Mate2 is a zero-footprint computer room cooling system for 7x24 temperature and humidity control and air filtration. It installs above a dropped ceiling and is easy to service, requiring only front access for maintenance.
Guadar este produto no seu dashboard
Você pode guardar este produto no seu dashboard para ve-lo depois. Você pode elimina-lo com facilidade do seu dashboard quando você já no quer ve-lo lá.
Please login or create an account to save this for later
- Bancos, Setor Financeiro e Seguradoras
- Governo
- Setor de Saúde
- Data Center/ Colocation / Hosting
- Educação
- Varejista e Atacadista
MMD36E, 8.3kW
The Liebert Mini-Mate2 is a zero-footprint computer room cooling system for 7x24 temperature and humidity control and air filtration. It installs above a dropped ceiling and is easy to service, requiring only front access for maintenance.
- Bancos, Setor Financeiro e Seguradoras
- Governo
- Setor de Saúde
- Data Center/ Colocation / Hosting
- Educação
- Varejista e Atacadista
Vantagens
Recursos
Especificações
The Liebert Mini-Mate is designed for data center cooling, humidity control and air filtration of small areas, such as computer, control and equipment rooms. The system installs above a dropped ceiling, is easy to install and service and requires only front access for maintenance. The Liebert Mini-Mate is available in nominal cooling capacities from 3.5 to 28 kW (1 to 8 tons), with air, water, glycol and chilled water models available in 50 and 60 Hz. All chilled water systems are self-contained units. Air, water and glycol cooled models are available in split-system configurations.
- Product Specifications
- Total Nominal Capacity kBtuh [kW]
- 28.4 [8.3]
- Net Sensible Capacity kBtuh [kW]
- 28.4 [8.3]
- Nominal Airflow [CFM]
- 885
- Total Capacity
- 32.5 [9.55]
- Heat Rejection Medium
- Air
- Controls and Monitoring
- iCOM CMS Monitoring & Management System
- Physical Characteristics
- Peso (lbs / kgs)
- 225
- Peso (lbs / kgs)
- 102
- Altura (pol/mm)
- 24
- Altura (pol/mm)
- 610
- Largura (pol/mm)
- 57 13/16
- Largura (pol/mm)
- 1468
- Profundidade (pol/mm)
- 30
- Profundidade (pol/mm)
- 762
- Liebert® Mini-Mate2 1 & 1.5 Ton Installer User Guide SL-10530
- Liebert® Mini-Mate2 2 and 3 Ton User Manual SL-10531
- Liebert® Mini-Mate2 5 Ton User Manual SL-10532
- Liebert Mini-Mate2 8 Ton User Manual SL-10533
- Liebert IS-UNITY-DP User Manual for Liebert Mini-Mate2 and Liebert DataMate
- Liebert iCOM CMS Quick Installation Guide - Mini-Mate2
- Vertiv™ Liebert® Mini-Mate2 System Design Catalog SL-10525
- Liebert® Mini-Mate2 2 and 3 Ton System Design Catalog SL-10535
- Liebert® Mini-Mate2 5 Ton System Design Catalog SL-10536
- Liebert Mini-Mate2 8 Ton System Design Catalog SL-10537
- Liebert® Mini-Mate2 1 & 1.5 Ton Guide Specifications SL-10525GS
- Liebert® Mini-Mate2 2 & 3 Ton Guide Specifications SL-10535GS
- Liebert Mini-Mate2 5 Ton Guide Specifications (SL-10536GS)
- Liebert Mini-Mate2 8 Ton Guide Specifications (SL-10537GS)
*Para ver downloads específicos de modelos, é necessário acessar a página de produto específica do modelo, selecionando o nome do modelo na tabela de especificações acima.
