PW011, 11kW
The Liebert PCW chilled water system offers the industry’s highest efficiency, protection and capacity per footprint for server room cooling. network closets and other small IT spaces.
Guadar este produto no seu dashboard
Você pode guardar este produto no seu dashboard para ve-lo depois. Você pode elimina-lo com facilidade do seu dashboard quando você já no quer ve-lo lá.
Please login or create an account to save this for later
- Bancos, Setor Financeiro e Seguradoras
PW011, 11kW
The Liebert PCW chilled water system offers the industry’s highest efficiency, protection and capacity per footprint for server room cooling. network closets and other small IT spaces.
- Bancos, Setor Financeiro e Seguradoras
Vantagens
Recursos
Industry’s highest capacity per footprint
Especificações
The Liebert PCW is highly configurable and available in a wide range of capacities. The units feature variable speed EC fans that reduce motor energy usage by 10-30%, compared to standard AC motors, and are more efficient than centrifugal blowers even when operating at 100% fan speed. The units feature motorized control valves that control water flow and are managed by the Liebert iCOM unit control to maintain the desired cooling capacity. The Liebert PCW offers unique, floor-level air discharge that reduces the mixing of hot and cold air to improve efficiency. Downflow models provide front, left side and right side discharge and upflow models provide front and rear return options.
- Product Specifications
- Total Nominal Capacity kBtuh [kW]
- 37.5 [11]
- Net Sensible Capacity kBtuh [kW]
- 38 [11.1]
- Nominal Airflow [CFM]
- 2000
- Total Capacity
- 39.6 [11.6]
- Airflow Direction
- Upflow and Downflow
- Heat Rejection Medium
- Chilled Water
- Capacity Modulation
- Variable speed EC fans
- Controls and Monitoring
- Liebert iCOM Unit Controls
- Physical Characteristics
- Peso (lbs / kgs)
- 575
- Peso (lbs / kgs)
- 261
- Altura (pol/mm)
- 77 9/16
- Altura (pol/mm)
- 1970
- Largura (pol/mm)
- 34 1/2
- Largura (pol/mm)
- 876
- Profundidade (pol/mm)
- 34 5/8
- Profundidade (pol/mm)
- 879
*Para ver downloads específicos de modelos, é necessário acessar a página de produto específica do modelo, selecionando o nome do modelo na tabela de especificações acima.
