Vertiv™ CoolChip CDU, 600
Quick Access
Specifications
Technical Specifications
Vertiv™ CoolChip CDU, 600
- Product Specifications
- Net Sensible Nominal Capacity kBtuh[kW]*
- 600 kW at 7.2⁰F (4⁰C) approach temperature difference
- Controls and Monitoring
- Color touch screen display, Communication via Modbus RTU (RS485) and TCP/IP
- Key Components
- Redundant pump design, variable-speed pump controls, and integrated filtration
- Physical Characteristics
- Weight
- 1058 lbs
- Weight
- 480 kg
- Height
- 78.7 in
- Height
- 2000 mm
- Width
- 23.6 in
- Width
- 600 mm
- Depth
- 47.2 in
- Depth
- 1200 mm
*To see model-specific downloads, you will need to go to the model-specific product page by selecting the model name in the specifications chart above.
Vertiv™ CoolChip CDU, 600
As data centers adopt liquid cooling, fitting in new coolant distribution infrastructure can be a serious challenge. From hyperscale and colocation environments to edge applications, the Vertiv CoolChip CDU (the next generation of the Vertiv™ Liebert® XDU family) simplifies your work with the flexibility to support rear door heat exchangers or direct to chip liquid cooling. The Vertiv CoolChip CDU’s compact footprint allows for in-rack, end of row, or perimeter placement options. When you incorporate the Vertiv CoolChip CDU, you can easily distribute coolant to efficiently manage power dense deployments with liquid-to-liquid heat exchange up to 100 kw, 450 kW, 600 kW, or 1,350 KW, and liquid-to-air heat exchange up to 70kW. The Vertiv CoolChip CDU provides a compact footprint for deployment flexibility, efficient coolant distribution to manage power dense applications, precise temperature control to eliminate thermal shock, redundant pumps and dual power feeds for reliable operation, and remote monitoring and communications for added peace of mind.
