Product Model
Vertiv™ Liebert® EXS UPS V-Models 15-40kVA/kW 208/220V
Specifications
Technical Specifications
Vertiv™ Liebert® EXS UPS V-Models 15-40kVA/kW 208/220V
The Liebert® EXS is a monolithic transformer-free UPS that provides on-line protection using a three-phase (in/out), 208/220V design that is optimized in a compact tower cabinet. Flexible configurations offer users a simple, reliable and economical power solution.
Warranty : One Year Limited Warranty Against Defects in Material and Workmanship- Product Overview
- Power Rating
- 15kVA/kW, 20kVA/kW, 30kVA/kW, 40kVA/kW
- Input Voltage Range
- 208, 220
- Output Voltage Range
- 208, 220
- Efficiency
- 93.4
- Wiring
- 4W+G
*To see model-specific downloads, you will need to go to the model-specific product page by selecting the model name in the specifications chart above.
Benefits
Complete Integrated Solution
Flexible and optimized design lowering complexity and supports faster deployments
Extended battery runtime options
High availability reduces downtime
Fast, easy installation and serviceability
High power density
Compact Footprint
Diverse applications scenarios; In-Row, Room and against-the wall
Improved visibility and control via intelligent local and remote monitoring
Features
Complete Integrated Tower Design
Optional Top fan install capability
High power density
Unity output power factor
Efficient double conversion operation up to 93.4%
ECO mode efficiency up to 99%
Integrated output power distribution options
Integrated maintenance bypass
Frequency and voltage regulation
Intelligent battery management
Programmable dry contacts
Robust short circuit withstand ratings
Network communication card allows connectivity to monitor critical systems
Vertiv™ Power Insight Monitoring available
Vertiv™ LIFE Services remote management capable.
Find Your Area Contact
Products Support Contacts
Vertiv (Liebert Services)
Email Contact
+1 800 543 2378
610 Executive Campus Drive
Westerville Ohio 43082
USA
Product areas of focus:
Uninterruptible Power Supplies (UPS), Power Distribution, Thermal Management, Integrated Solutions, Racks and Containment
Change
Vertiv™ Liebert® EXS V-Models
| Models | Power Rating | Input Voltage Range | Output Voltage Range | Efficiency | Wiring | Height (in) | Width (in) | Depth (in) | Standard Runtime Weight (lbs) | Extended Runtime Weight (lbs) |
|---|---|---|---|---|---|---|---|---|---|---|
|
Liebert® EXS V Model 15kVA, 208V |
15kVA/kW |
208/220 | 208/220 | 93.4 | 4W+G | 78.7 | 23.6 | 39.3 | 1212 | 1455 |
|
Liebert® EXS V Model 20kVA, 208V |
20kVA/kW |
208/220 | 208/220 | 93.4 | 4W+G | 78.7 | 23.6 | 39.3 | 1212 | 1455 |
|
Liebert® EXS V Model 30kVA, 208V |
30kVA/kW |
208/220 | 208/220 | 93.4 | 4W+G | 78.7 | 23.6 | 39.3 | 1521 | 762.6 |
|
Liebert® EXS V Model 40kVA, 208V |
40kVA/kW |
208/220 | 208/220 | 93.4 | 4W+G | 78.7 | 23.6 | 39.3 | 1543 | 762.6 |
