Quick Access
Product Model
Integrated 120V Inverter Systems
Free up floor space by powering AC and DC loads in a single subrack with a common battery bank
Minimize energy consumption with up to 95.2% inverter efficiency in normal AC-AC mode
Maximize site availability thanks to zero transfer time from grid to battery
Seamlessly manage your complete back-up solution locally or remotely through a single interface
Quick Access
Specifications
Technical Specifications
Integrated 120V Inverter Systems
- Physical Characteristics
- Weight
- 9.5 to 16.3 kg
- Height
- 88.9 to 177.8 mm
- Width
- 444.5 to 535.9 mm
- Depth
- 421.6 mm
Brochures and Data Sheets
*To see model-specific downloads, you will need to go to the model-specific product page by selecting the model name in the specifications chart above.
Integrated 120V Inverter Systems
Benefits
Free up floor space by backing-up AC and DC loads with a common battery bank
Minimize energy consumption with up to 95.2% inverter efficiency in normal AC-AC mode and 96.2% rectifier efficiency
Maximize site availability thanks to zero transfer time from grid to battery
Seamlessly manage your complete back-up solution locally or remotely through a single advanced interface
Features
Market leading inverter power density (19 VA/in3)
Same battery bank for both AC and DC loads
Long battery back up for both AC and DC loads
Zero transfer time from AC mains to battery sources
