VA4N31A0
The Vertiv™ Geist™ Rack Transfer Switch (RTS) VA4N31A0 delivers redundant power to single corded devices. It is a 30A, 208V single phase, unit level monitored rPDU with 1 NEMA L6-30R outlet and dual input L6-30P plugs providing 4.9kW in max power capacity. It provides redundant power to single corded devices and ensures continuity in the event of power loss. It can detect power loss on the main source and automatically switch it to the secondary source in less than 4 to 8 milliseconds.
Saved This Product to Your Dashboard
You just saved this product to your dashboard to view at a later time. You can easily remove the item from your dashboard when you no longer wish to have it saved.
Please login or create an account to save this for later
- Banking
- Financial and Insurance
- Data Center/Colocation/Hosting
- Education
- Government
- Healthcare
- Military
- Defense
- Aerospace and Missile
- Telecom
- Retail and Wholesale
VA4N31A0
The Vertiv™ Geist™ Rack Transfer Switch (RTS) VA4N31A0 delivers redundant power to single corded devices. It is a 30A, 208V single phase, unit level monitored rPDU with 1 NEMA L6-30R outlet and dual input L6-30P plugs providing 4.9kW in max power capacity. It provides redundant power to single corded devices and ensures continuity in the event of power loss. It can detect power loss on the main source and automatically switch it to the secondary source in less than 4 to 8 milliseconds.
- Banking
- Financial and Insurance
- Data Center/Colocation/Hosting
- Education
- Government
- Healthcare
- Military
- Defense
- Aerospace and Missile
- Telecom
- Retail and Wholesale
Benefits
Features
Specifications
The Vertiv™ Geist™ Rack Transfer Switch (RTS) delivers redundant power to single corded devices. Two independent power inputs enables users to connect to a primary and secondary power source. The Vertiv™ Geist™ Rack Transfer Switch automatically detects the loss of power and switches the power load to the alternative power source in less than 4-8 milliseconds without the need for human intervention. This ensures equipment remains powered until the primary power source returns providing ultimate mission-critical power reliability. The Rack Transfer Switch is an open transition switch utilizing a break-before-make process for transferring between the primary and secondary power source. This method of switching does not require phase synchronization between the two power feeds making it suitable for use in both data center and edge locations. It also includes enhanced redundant switches and fail-safe fused thermistors to mitigate current surge during transfers ensuring critical equipment is protected during fail-over.
- Power Description
- Frequency
- 50/60Hz
- Interfaces/Ports
- Protocols
- DHCP, HTTP, HTTPS, IPv4, IPv6, LDAP, NTP, RADIUS, RSTP, SSH, SMTP, SNMP (v1/v2c/v3), Syslog, TACACS+
- Management
- Listings
- RoHS Compliant, FCC Part 15 Class A Compliance, UL Listed 62368
- Operational Conditions
- Operating Temperature
- 60C / 140F
- Physical Characteristics
- Weight
- 19 lbs
- Weight
- 8.62 kgs
- Height
- 1.72 in
- Height
- 44 mm
- Width
- 17 in
- Width
- 432 mm
- Depth
- 18 in
- Depth
- 457 mm
- Frequency
- 50/60Hz
- Operating Temperature
- 60C / 140F
- Listings
- RoHS Compliant, FCC Part 15 Class A Compliance, UL Listed 62368
